The Inner Wall Shot Blasting Machine is a specialized piece of equipment designed for the effective cleaning and surface preparation of the internal walls of pipes and tubes. This machine utilizes high-speed abrasive blasting to remove contaminants such as rust, scale, and old coatings, ensuring a clean and smooth internal surface.
Ideal for applications in industries such as oil and gas, construction, and manufacturing, the machine features adjustable blasting settings to accommodate different pipe diameters and internal surface conditions. Its robust design and advanced technology ensure consistent performance and reliable operation.
Manufactured with high-quality materials, this shot blasting machine offers durability and long-term performance, making it a cost-effective solution for industrial cleaning and maintenance tasks.
Applications
Cleaning internal surfaces of pipes and tubes
Surface preparation for oil and gas pipelines
Maintenance and refurbishment in construction and manufacturing
Pre-coating preparation for metal components
Serial Number | designation | specifications |
1 | cleaning range | 850mm |
2 | Working pieces | φ≥2000mm |
3 | Blasting capacity | 2*249((kg/min) |
4 | Lifting capacity | 30T/H |
5 | Separation capacity | 30T/H |
6 | Ventilation Capacity (m³/h) | 10780m³/H |
7 | Shot blasting wheel diameter | 400mm |
8 | Suggested diameter of steel shot | 1.0-1.5mm |
9 | Steel shot consumption | 100g/㎡ |
10 | dust collector | automatic back flow vacuum cleaner |
