Optimize your metal surface preparation with our Iron Sheet Surface Shot Blasting Machine, designed to deliver exceptional performance for cleaning and texturizing iron sheets. This robust machine effectively removes rust, old coatings, and contaminants, providing a clean and uniform surface ready for further processing or coating.
Engineered for efficiency, our shot blasting machine utilizes a powerful blasting mechanism that ensures thorough surface treatment with minimal effort. The adjustable settings allow for precise control over blasting intensity, accommodating various iron sheet sizes and surface conditions.
Constructed with high-quality, durable materials, this machine is built to withstand heavy-duty use in industrial environments. Its user-friendly design and mobility make it easy to operate and maneuver, even in busy workshops or production lines.
Serial Number | designation | specifications |
1 | cleaning range | 850mm |
2 | Shot blasting efficiency | On concrete≥500㎡/h |
3 | Shot blasting motor power | 2*15kw |
4 | Walking motor | 1.5kw |
5 | Dust removal fan | 3kw |
6 | Blow back motor | 2.2KW |
7 | Shot blasting wheel diameter | 200mm |
8 | Walking speed | 0.5-20 m/min |
9 | Suggested diameter of steel shot | 1.0-1.5mm |
10 | Steel shot consumption | 100g/㎡ |
11 | dust collector | Eleven core automatic back flow vacuum cleaner |
Designation：cleaning range、specifications：550mm
Designation：cleaning range、Specifications：1000mm
Designation：cleaning range、Specifications：550mm、main shot blasting machine and dust collector Assembled together
